New R&D Peak 3kw/5kw High Capacity Generator Solar Power Station Solar Panel Generators
Product Introduction of the for household photovoltaic solar power generation:
| Model | NKH-3KW/NKH-5KW |
| Rated Power | 3000W/5000W |
| Voltage | 208VAC/220VAC/230VAC/240VAC |
| Selectable Voltage Range |
170-280VAC(For Personal Computers) 90-280VAC(For Home Appliances) |
| Frequency Range | 50Hz/60Hz(Auto sensing) |
| AC Voltage Regulation | 208VAC/220VAC/230VAC/240VAC士5% |
| Surge Power | 6000VA/10000VA |
| Efficiency (Peak)PV to INV | 97% |
| Efficiency(Peak)Battery to INV | 94% |
| Transfer Time | 10ms |
| Overlord Capacity |
1min@102%-110% Load, 10s@110% -130% Load, 3s@ 130%-150% Load, 0.2s@> 150% Load |
| Battery Voltage | 24VDC/48VDC |
| Floating Charge Voltage | 27VDC/54VDC |
| Overcharge Protection | 32VDC/64VDC |
| Maximum Charge Current | 60A/80A |
| Maximum PV Array Power | 1500W/5500W |
| MPPT Range Operating Voltage | 30-115VDC/120-430VDC |
| Maximum PV Array Open Circuit Voltage | 145VDC/450VDC |
| Maximum Charge Current | 120A/80A |
| Dimension D*W*H(mm) | 439*320*128 |
| Net Weight(kg) | 8/9.2 |
| Communication interface | USB/RS232/GPRS/WIFI |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature(℃) | 0- 55 |
| Storage Temperature(℃) | -15-60 |
Characteristics about the for household photovoltaic solar power generation:
1. Pure Sine Wave Inverter
2. Configurable input voltage range for home appliances and personal computers Via LCD setting
3. Configurable battery charging current based on applications via LCD setting
4. Configurable AC/Solar Charger priority via LCD setting
5. Compatible to mains voltage or generators power
Theory of the for household photovoltaic solar power generation:
This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Advantage/Selling points about the for household photovoltaic solar power generation:
1. Pure sine wave solar inverter
2. Output power factor 1.0
3. Wifi & GPRS Available for IOS and android
4. Inverter running without battery
5. Built-in 100A MPPT solar charger
6. High PV input voltage
7. Built-in anti-dusk kit for harsh environment
8. Smart battery charge design to optimize battery life
FAQ:
1. Q: What are your company's advantages?
A: Strong R&D team, independent R&D and production of major components, to control product quality is very strict.
2. Q: Can you provide OEM and ODM services?
A: Yes, we have a R&D team and need the minimum order quantity.
3. Question: What certificates have you obtained for your products?
A: Most of our solar products have obtained CE, FCC, UL and PSE certification, which can meet the import requirements of most countries.
4. Q: How about the delivery date?
A: It takes 5-10 days for samples and 25-45 days for mass production.
5. Q: Since it is a large capacity battery, how do you deliver it?
A: We have long-term cooperation with freight forwarders, who are specialized in battery transportation.
